Electric Cargo Bike KBO Ranger
Electric Cargo Bike KBO Ranger
Regular price
$1,699.00 USD
Regular price
$1,899.00 USD
Sale price
$1,699.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
In Frame and Removable 48V 17.5Ah Lithium-ion Battery with Samsung/LG Cells
A KBO Bike battery life is one of its most significant advantages, rated for 900 complete charge cycles. With an 840Wh battery capacity, you can ride up to 60 miles on a single charge.
Powerful 900W Peak Brushless Geared Hub Motor
Powered with a continuous 750W brushless geared hub motor, you won't have to worry about carrying heavy loads and climbing steep uphills.
SPECS AND COMPONENTS
-
Battery48V 17.5Ah Lithium-ion battery with LG cells
-
Range35-60 miles
-
Hub MotorSustained 750W brushless geared motor
-
Total Payload Capacity400 lbs
-
Recommended Rider Heights4'11" - 6'3"
-
Charger3.0 Amp Quick charger
-
Controller48V /22A
-
DisplayLCD backlight display
-
Weight77 lbs
-
Pedal Assist0-5 level
-
Tires20" x 3.0" CST puncture-resistant tires
-
DerailleurShimano 7 speed derailleur
-
Rear LightIntegrated brake tail-light
-
BrakeDual 180mm mechanical disc brakes
-
ChainKMC chain
-
SensorSensitive cadence sensor and speed sensor
-
Crank170mm forged alloy
-
ThrottleTwist throttle on the right
-
PedalAlloy pedal with reflectors
-
Bike Frame6061 Aluminum frame
-
Front Light48V LED light
-
SaddleSturdy and comfy saddle
-
Seat PostDiameter 33.8mm/length 350mm
-
Center standHeavy-duty aluminum
-
SpokesStainless spokes(Front 13G/Rear 12G)
-
Stem Diameter30mm
-
Handlebar DiameterSides 28.6mm/middle 31.8mm
GEOMETRY
- 1 . Total Length69"
- 2 . Handlebar Height53"
- 3 . Wheelbase47"
- 4 . Minimum Seat Height27.5"
- 5 . Maximum Seat Height37.5"
- 6 . Chain Stay Length21.6"
- 7 . Standover Height15.7"
- 8 . Reach15.7"
- 9 . Wheel Diameter20"
- 10 . Head Tube Length7.1"
- 11 . Handlebar Length28.3"
- 12 . Seat Tube Length15.6"
- 13 . Minimum Pedal Height4.7"
